The selection of parts used and the ingenuity of board design have resulted in an extremely low-noise finish.
An OD that compactly houses a famous instrument characterized by a pleasant midrange. Covers everything from boosters to low gain overdrives, creating the foundation of your sound. Equipped with a 27V booster circuit using a charge pump IC. The selection of parts used and the ingenuity of board design have resulted in an extremely low-noise finish. Adopts a specially designed housing and large pointer knob. ・Bypass switch A buffered bypass method is used that passes through the buffer circuit even when bypassing. When the power supply is lost, the device automatically switches to the bypass state using mechanical relay control, and when power is supplied again, it returns to the state it was in when the power was last turned off. ・Voltage monitoring function This unit constantly monitors the input voltage, and when it falls below or exceeds a certain level of 9V, the LED will blink and it will automatically go into bypass mode. Please check the remaining capacity of your battery and the voltage of your power supply. ・Specifications Control: OUTPUT, TREBLE, GAIN Size: Width approx. 125mm x Height approx. 97mm x Height approx. 53mm *Includes protruding parts such as knobs, switches, jacks, screws, etc. Power source: 9V battery or DC adapter *9vDC/center negative/2.1
mm pin Current consumption: Approx. 31mA Blue LED indicator Buffer bypass 12 months warranty included
