USB PIR Motion Sensor Switch 5A DC 5-24V Body Infrared Sensing Detector Switch

USB PIR Motion Sensor Switch 5A DC 5-24V Body Infrared Intelligent Sensing Detector Switch for LED Strip Light Feature: With PIR motion sensor, it can detect human motion by detecting the infrared rays emitted by the human body. 120 degree cone angle detection range. High sensitivity and stability, effectively saving energy and improving efficiency. Intelligent induction, automatically delay shutdown after the person leaves. Widely used in motion activated lighting for automatic lighting in hallways, bathrooms, basements, warehouses, garages and more. The USB port makes it convenient for standby. Powered by a mobile phone, charging bank or other device with a USB port, the output voltage is equal to the input voltage, and the power consumption is low. Built-in temperature compensation chip to reduce the effect of temperature on the sensing distance.

Specification: Working voltage: 5V-24 DC Output current: 5A Operating temperature: -15°C-38°C Function: infrared human body sensor switch Quiescent current: <50uA Trigger Mode: Continuous Trigger Output mode: induction output Sensing distance: 5-7m Sensing angle: 120 degrees Induction mode: passive Time range: 15s by default, adjustable Color: black, white (optional) Shell material: ABS Body size: about 54*40*22mm

Note: Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you! Please allow 1-2cm measuring deviation due to manual measurement.
